Defendo – Dual Reflective Film | Platina Series
This film provides clearer vision at night by providing improved outward vision, rejects solar energy up to 75%, cuts glare up to 84%, and blocks 99% of harmful UV rays.
Types of Defendo - Dual Reflective Film
Dual Reflective Charcoal 15
Dual Reflective Charcoal 15 Specification
Properties | Unit |
Thickness | 2 Mil |
Visible Light Transmittance | 15% |
Visible Light Reflectance | 47% |
Solar Energy Transmittance | 13% |
Solar Energy Reflectance | 44% |
Solar Energy Absorbance | 43% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 84% |
Shading Coefficient | 0.29 |
Emissivity | 0.77 |
U Factor (BTU /HR./SQ.FT.) | 1.08 |
Total Solar Energy Rejection | 75% |
Dual Reflective Charcoal 25
Dual Reflective Charcoal 25 Specification
Properties | Unit |
Thickness | 2 Mil |
Visible Light Transmittance | 25% |
Visible Light Reflectance | 40% |
Solar Energy Transmittance | 19% |
Solar Energy Reflectance | 36% |
Solar Energy Absorbance | 45% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 74% |
Shading Coefficient | 0.36 |
Emissivity | 0.68 |
U Factor (BTU /HR./SQ.FT.) | 1.03 |
Total Solar Energy Rejection | 69% |
Dual Reflective Charcoal 45
Dual Reflective Charcoal 45 Specification
Properties | Unit |
Thickness | 2 Mil |
Visible Light Transmittance | 45% |
Visible Light Reflectance | 15% |
Solar Energy Transmittance | 36% |
Solar Energy Reflectance | 14% |
Solar Energy Absorbance | 50% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 51% |
Shading Coefficient | 0.57 |
Emissivity | 0.75 |
U Factor (BTU /HR./SQ.FT.) | 1.07 |
Total Solar Energy Rejection | 50% |
