High Performance Film | Premium Series
This is a double ply (1.5 mil) 37 microns thick dyed film with a metallic sheen, which has been specially developed to provide higher heat rejection and to be highly energy efficient, without compromising on light transmission.
Types of High Performance Film
HP Charcoal 5
HP Charcoal 5 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 4% |
| Visible Light Reflectance | 5% |
| Solar Energy Transmittance | 21% |
| Solar Energy Reflectance | 12% |
| Solar Energy Absorbance | 67% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 96% |
| Shading Coefficient | 0.46 |
| Emissivity | 0.78 |
| U Factor (BTU /HR./SQ.FT.) | 1.03 |
| Total Solar Energy Rejection | 61% |
HP Charcoal 50
HP Charcoal 50 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 54% |
| Visible Light Reflectance | 8% |
| Solar Energy Transmittance | 55% |
| Solar Energy Reflectance | 7% |
| Solar Energy Absorbance | 38% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 41% |
| Shading Coefficient | 0.76 |
| Emissivity | 0.88 |
| U Factor (BTU /HR./SQ.FT.) | 1.15 |
| Total Solar Energy Rejection | 34% |
HP Natural 20
HP Natural 20 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 21% |
| Visible Light Reflectance | 7% |
| Solar Energy Transmittance | 24% |
| Solar Energy Reflectance | 13% |
| Solar Energy Absorbance | 63% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 77% |
| Shading Coefficient | 0.49 |
| Emissivity | 0.77 |
| U Factor (BTU /HR./SQ.FT.) | 1.13 |
| Total Solar Energy Rejection | 58% |
HP Natural 35
HP Natural 35 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 39% |
| Visible Light Reflectance | 14% |
| Solar Energy Transmittance | 36% |
| Solar Energy Reflectance | 16% |
| Solar Energy Absorbance | 48% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 57% |
| Shading Coefficient | 0.57 |
| Emissivity | 0.8 |
| U Factor (BTU /HR./SQ.FT.) | 1.11 |
| Total Solar Energy Rejection | 51% |
HP Green 30
HP Green 30 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 35% |
| Visible Light Reflectance | 7% |
| Solar Energy Transmittance | 43% |
| Solar Energy Reflectance | 8% |
| Solar Energy Absorbance | 49% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 61% |
| Shading Coefficient | 0.66 |
| Emissivity | 0.84 |
| U Factor (BTU /HR./SQ.FT.) | 1.12 |
| Total Solar Energy Rejection | 43% |
HP Blue 35
HP Blue 35 Specification
| Properties | Unit |
| Thickness | 1.5 Mil |
| Visible Light Transmittance | 41% |
| Visible Light Reflectance | 10% |
| Solar Energy Transmittance | 40% |
| Solar Energy Reflectance | 11% |
| Solar Energy Absorbance | 49% |
| Ultra Violet Transmittance | <1% |
| Glare Reduction | 55% |
| Shading Coefficient | 0.62 |
| Emissivity | 0.80 |
| U Factor (BTU /HR./SQ.FT.) | 1.10 |
| Total Solar Energy Rejection | 46% |
