IR Rejection Film | Platina Series
IR Rejection Film is crafted with a primary focus on enhancing film performance. Designed to maximize heat rejection while maintaining optimal visibility, this film stands out for its ability to deliver superior results without the use of metalized content.
Types of IR Rejection Film
HHR Green 70
HHR Green 70 Specification
Properties | Unit |
Thickness | 1.5 Mil |
Visible Light Transmittance | 69% |
Visible Light Reflectance | 7% |
Solar Energy Transmittance | 46% |
Solar Energy Reflectance | 5% |
Solar Energy Absorbance | 49% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 24% |
Shading Coefficient | 0.70 |
Emissivity | 0.89 |
U Factor (BTU /HR./SQ.FT.) | 1.13 |
Total Solar Energy Rejection | 40% |
NIR Blocking at 1025 NM | 82% |
SHR Natural 70
SHR Grey 70
HHR Grey 70
HHR Grey 70 Specification
Properties | Unit |
Thickness | 2 Mil |
Visible Light Transmittance | 79% |
Visible Light Reflectance | 9% |
Solar Energy Transmittance | 47% |
Solar Energy Reflectance | 7% |
Solar Energy Absorbance | 46% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 13% |
Shading Coefficient | 0.69 |
Emissivity | – |
U Factor (BTU /HR./SQ.FT.) | – |
Total Solar Energy Rejection | 42% |
NIR Blocking at 1025 NM | 76% |
Ice Cool Blast 80
