Reflective Film | Classic Series
Reflective Films are coated with a micro-thin, partially transparent layer of metal and have a mirror like finish. They prevent visibility from outside (area of greater light intensity) during the day and vice-versa during the night. Total solar energy rejection is on higher side.
Types of Reflective Film
Reflective Silver 20
Reflective Silver 20 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 18% |
| Visible Light Reflectance | 58% |
| Solar Energy Transmittance | 13% |
| Solar Energy Reflectance | 53% |
| Solar Energy Absorbance | 34% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 80% |
| Shading Coefficient | 0.25 |
| Emissivity | 0.64 |
| U Factor (BTU /HR./SQ.FT.) | 1.01 |
| Total Solar Energy Rejection | 78% |
Reflective Silver 35
Reflective Silver 35 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 36% |
| Visible Light Reflectance | 38% |
| Solar Energy Transmittance | 28% |
| Solar Energy Reflectance | 37% |
| Solar Energy Absorbance | 35% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 60% |
| Shading Coefficient | 0.43 |
| Emissivity | 0.72 |
| U Factor (BTU /HR./SQ.FT.) | 1.05 |
| Total Solar Energy Rejection | 63% |
Reflective Silver 50
Reflective Silver 50 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 49% |
| Visible Light Reflectance | 26% |
| Solar Energy Transmittance | 38% |
| Solar Energy Reflectance | 26% |
| Solar Energy Absorbance | 36% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 46% |
| Shading Coefficient | 0.56 |
| Emissivity | 0.78 |
| U Factor (BTU /HR./SQ.FT.) | 1.07 |
| Total Solar Energy Rejection | 52% |
RA Charcoal 10
RA Charcoal 20
RA Charcoal 35
Reflective Green 10
Reflective Green 10 Specification
Properties | Unit |
Thickness | 2 Mil |
Visible Light Transmittance | 13% |
Visible Light Reflectance | 23% |
Solar Energy Transmittance | 12% |
Solar Energy Reflectance | 32% |
Solar Energy Absorbance | 56% |
Ultra Violet Transmittance | < 1% |
Glare Reduction | 86% |
Shading Coefficient | 0.32 |
SHGC | 0.27 |
Emissivity | 0.66 |
U Factor (BTU /HR./SQ.FT.) | 1.01 |
Total Solar Energy Rejection | 73% |
Reflective Blue 15
Reflective Blue 15 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 13% |
| Visible Light Reflectance | 31% |
| Solar Energy Transmittance | 11% |
| Solar Energy Reflectance | 37% |
| Solar Energy Absorbance | 52% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 86% |
| Shading Coefficient | 0.29 |
| Emissivity | 0.69 |
| U Factor (BTU /HR./SQ.FT.) | 1.01 |
| Total Solar Energy Rejection | 75% |
Reflective Grey 10
Reflective Grey 10 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 8% |
| Visible Light Reflectance | 13% |
| Solar Energy Transmittance | 9% |
| Solar Energy Reflectance | 27% |
| Solar Energy Absorbance | 64% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 92% |
| Shading Coefficient | 0.31 |
| SHGC | 0.27 |
| Emissivity | 0.68 |
| U Factor (BTU /HR./SQ.FT.) | 1.03 |
| Total Solar Energy Rejection | 73% |
Reflective Bronze 10
Reflective Bronze 10 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 10% |
| Visible Light Reflectance | 21% |
| Solar Energy Transmittance | 10% |
| Solar Energy Reflectance | 31% |
| Solar Energy Absorbance | 59% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 89% |
| Shading Coefficient | 0.31 |
| SHGC | 0.26 |
| Emissivity | 0.66 |
| U Factor (BTU /HR./SQ.FT.) | 1.01 |
| Total Solar Energy Rejection | 74% |
Reflective Gold 15
Reflective Gold 15 Specification
| Properties | Unit |
| Thickness | 2 Mil |
| Visible Light Transmittance | 14% |
| Visible Light Reflectance | 46% |
| Solar Energy Transmittance | 12% |
| Solar Energy Reflectance | 44% |
| Solar Energy Absorbance | 44% |
| Ultra Violet Transmittance | < 1% |
| Glare Reduction | 84% |
| Shading Coefficient | 0.28 |
| Emissivity | 0.69 |
| U Factor (BTU /HR./SQ.FT.) | 1.04 |
| Total Solar Energy Rejection | 76% |
